Stainless Steel 3D Printing Explained: Processes, Properties & Applications

Banner Image Courtesy of Hi3DP

Processes for Stainless Steel 3D Printing

1. Selective Laser Melting (SLM) / Laser Powder Bed Fusion (LPBF)

• How it works: A high-powered laser selectively melts layers of stainless steel powder according to a digital model.

• Advantages: Produces near fully dense parts with excellent mechanical properties and fine detail resolution.

• Common alloys: 316L, 17-4 PH.

• Best for: High-performance engineering components, medical devices, aerospace parts.

2. Electron Beam Melting (EBM)

• How it works: Uses an electron beam in a vacuum to melt stainless steel powder layer by layer.

• Advantages: Lower residual stresses, suitable for larger parts.

• Limitations: Coarser surface finish compared to SLM.

• Best for: Large structural components where surface finish can be post-processed.

3. Binder Jetting

• How it works: A liquid binder selectively joins stainless steel powder particles, followed by sintering or infiltration.

• Advantages: High build speed, no need for support structures during printing.

• Limitations: Requires post-processing to achieve full density and strength.

• Best for: Prototypes, low-load components, and cost-sensitive production.

4. Directed Energy Deposition (DED)

• How it works: A focused energy source (laser or electron beam) melts stainless steel wire or powder as it is deposited.

• Advantages: Can repair or add features to existing parts, suitable for large builds.

• Limitations: Lower resolution than powder bed methods.

• Best for: Industrial repairs, large-scale components.

Stainless Steels That Used in 3D Printing

Properties of 3D Printed Stainless Steel

1. Mechanical Properties

• Tensile Strength: 480–1100 MPa depending on alloy and heat treatment.

• Yield Strength: 170–1000 MPa.

• Hardness: Can be increased through heat treatment, especially in precipitation-hardening grades.

2. Corrosion Resistance

• Austenitic grades like 316L offer excellent resistance to chlorides and acids, making them ideal for marine and chemical environments.

• Precipitation-hardening grades provide a balance of strength and corrosion resistance.

3. Density & Porosity

• Powder bed fusion methods can achieve >99% density with optimized parameters.

• Porosity is minimized through proper laser power, scan strategy, and powder quality.

4. Surface Finish

• As-printed surfaces are typically rougher than machined stainless steel (Ra 6–12 μm).

• Post-processing, such as machining, polishing, or electropolishing, is often used for critical surfaces.

Properties of SLM 3D Printed Stainless Steel at Hi3DP:

Stainless Steel 316L:

Stainless Steel 17-4PH:

Advantages of Stainless Steel 3D Printing

1. Design Freedom: Enables complex geometries, internal channels, and lattice structures that are impossible with traditional methods.

2. Material Efficiency: Minimal waste compared to subtractive machining.

3. Rapid Prototyping: Accelerates design iteration and testing.

4. Customization: Produces tailored parts for specific applications or patient-specific medical devices.

5. High Performance: Maintains stainless steel’s inherent strength and corrosion resistance.

6. Part Consolidation: Combines multiple components into a single printed part, reducing assembly time and potential failure points.

Limitations & Challenges

1. Printing Defects

• Porosity: Can reduce mechanical strength if not controlled.

• Warping & Residual Stress: Caused by rapid heating and cooling cycles.

• Cracking: More common in certain grades without optimized parameters.

2. Cost Factors

• Material Cost: Stainless steel powder is more expensive than bulk material.

• Machine Cost: Metal AM systems require significant investment.

• Post-Processing: Heat treatment, machining, and polishing add time and expense.

3. Design Constraints

• Support structures are often required for overhangs.

• Minimum wall thickness typically ~0.8–1.0 mm for structural integrity.

4. Alloy Limitations

• Not all stainless steel grades are printable due to cracking susceptibility or poor powder flowability.

Applications Across Industries

Aerospace

Stainless steel 3D printing is used for high-strength, corrosion-resistant components such as engine parts, brackets, and structural supports. The ability to produce lightweight yet durable parts helps improve fuel efficiency and performance.

Medical

In the medical field, stainless steel’s biocompatibility and corrosion resistance make it ideal for surgical instruments, orthopedic implants, and dental devices. Additive manufacturing allows for patient-specific designs that improve fit and function.

Automotive & Motorsports

Performance vehicles benefit from stainless steel’s strength and durability. 3D printing enables the creation of custom exhaust components, brackets, and tooling with optimized geometries.

Oil & Gas

Corrosion-resistant stainless steel parts are essential for harsh environments. 3D printing allows for rapid production of replacement parts, reducing downtime in critical operations.

Food Processing

Stainless steel’s hygienic properties make it suitable for food-grade equipment. Additive manufacturing can produce complex, easy-to-clean components that meet strict safety standards.

Industrial Tooling

Custom jigs, fixtures, and molds can be produced quickly and tailored to specific manufacturing needs, improving efficiency and reducing lead times.
